What Is EQ? Shaping the Tone of Every Track

What is EQ in mixing?

EQ (equalization) is the process of boosting or cutting specific frequency ranges to change how a sound feels in a mix. Think of it as tone-shaping with a scalpel.

The frequency spectrum (simple map)

• Sub bass: 20 to 60 Hz
• Bass: 60 to 150 Hz
• Low mids: 150 to 400 Hz
• Mids: 400 Hz to 2 kHz
• Upper mids: 2 to 5 kHz
• Presence and air: 5 to 16 kHz

Common types of EQ

High-pass and low-pass filters

Filters remove everything below or above a cutoff point.

Bell (parametric) EQ

A bell boost or cut targets one frequency area with a set bandwidth (Q).

Shelf EQ

A shelf raises or lowers everything above (high shelf) or below (low shelf) a frequency.

Practical EQ moves (safe starting points)

Vocals

• High-pass to remove rumble (start around 80 to 120 Hz)
• Reduce muddiness in the 200 to 400 Hz area if needed
• Add clarity carefully in the 2 to 5 kHz zone

Kick and bass

• Decide who owns the deepest low end
• Cut a little where the other one needs space

Acoustic guitar

• High-pass to avoid low-end buildup
• Control harshness around 2 to 4 kHz with small cuts

Drum overheads

• High-pass to reduce room rumble
• Add a touch of air with a gentle high shelf if the cymbals feel dull

EQ workflow: how to make decisions fast

1) Listen in context, not solo 2) Identify the problem (mud, harsh, boxy, thin) 3) Use a narrow band to find it, then widen slightly to fix it 4) Level-match and compare

EQ and compression together

EQ shapes tone; compression shapes dynamics. Many mixes get easier when you do gentle EQ cleanup before compression, then fine-tune after.

FAQ

Is it better to cut or boost?

Cutting is usually safer. Boost when you have a clear reason and the source can handle it.

What is Q on an EQ?

Q controls bandwidth. Higher Q means a narrower band.

Related reading

If compression still feels confusing, read our plain-English guide to audio compression.
